STANDARD PROFILE SYSTEMS
Machine guards are constructed using stainless steel box profiles.

In this system, steel wires are mounted inside the panels with clips. There are paint options for the fence wire, while the remaining aluminium parts are left in their natural colour or painted in the desired RAL colour to complete production.

Panel-post connections are made using aluminium BLB clamps and LBPS brackets.
System Height : 1200 / 2200 mm
Board Height : 1020 / 2020 mm
Board Width : 1000 /1200 / 1500 mm
Board Frame Meterial : 30*50*1,5 mm Box  Profile
Board Safety Wire : ø 3,5 mm/ 50*50 mm Steel
Standard Panel Color : Board: Natural Steel Color/ Fens: Ral 9005 (Black)
Board Installation Types : BLB-LBPS System
Post Material : 50*50*1,5 mm Box Profile
Post Installation Types : Steel Dowels
Standard Post Color : Natural Stainless Steel



  • Detail 2.1
  • Detail 2.2
  • Detail 2.3
  • Detail 2.3
  • Detail 2.3
  • Detail 8.1
  • Detail 8.2
  • Detail 8.3
